ETAPE DE REALIZARE A DESENULUI

Customization file loaded successfully. Customization Group: ACAD

Customization file loaded successfully. Customization Group: CUSTOM

Customization file loaded successfully. Customization Group: IMPRESSION

Customization file loaded successfully. Customization Group: EXPRESS



Regenerating model.

AutoCAD Express Tools Copyright 2002-2004 Autodesk, Inc.

AutoCAD menu utilities loaded.

Command: COMMANDLINE

Command: DASHBOARD

Command: '_limits

Reset Model space limits:

Specify lower left corner or [ON/OFF] <0.0000,0.0000>:

Specify upper right corner <12.0000,9.0000>: 210,297

Command: <Grid on>

Command:

Command: '_zoom

Specify corner of window, enter a scale factor (nX or nXP), or

[All/Center/Dynamic/Extents/Previous/Scale/Window/Object] <real time>: _all

Regenerating model.

Command:

Command:

Command: _cylinder

Specify center point of base or [3P/2P/Ttr/Elliptical]:..0.000 100.000 18.000

Specify base radius or [Diameter]: d

Specify diameter: 24

Specify height or [2Point/Axis endpoint]: 16

Command:

Command:

Command: _-view Enter an option

[?/Delete/Orthographic/Restore/Save/sEttings/Window]: _swiso Regenerating model.

Command:

Command:

Command: _chamfer

(TRIM mode) Current chamfer Dist1 = 0.0000, Dist2 = 0.0000

Select first line or [Undo/Polyline/Distance/Angle/Trim/mEthod/Multiple]: d

Specify first chamfer distance <0.0000>: 2

Specify second chamfer distance <2.0000>:

Select first line or [Undo/Polyline/Distance/Angle/Trim/mEthod/Multiple]:

<Snap off>

Base surface selection

Enter surface selection option [Next/OK (current)] <OK>:


Specify base surface chamfer distance <2.0000>:

Specify other surface chamfer distance <2.0000>:

Select an edge or [Loop]: Select an edge or [Loop]:

Command:

Command:

Command: _cylinder

Specify center point of base or [3P/2P/Ttr/Elliptical]: 0.000 100.000 18.000

Specify base radius or [Diameter] <12.0000>:d

Specify base radius or [Diameter] <24.0000>:20 Specify height or [2Point/Axis endpoint] <16.0000>: -104

Command:

Command:

Command: _cylinder

Specify center point of base or [3P/2P/Ttr/Elliptical]: 0.000 100.000 0.000

Specify base radius or [Diameter] <10.0000>: d

Specify diameter <20.0000>: 35

Specify height or [2Point/Axis endpoint] <-104.000>: -4

Command:

Command:

Command: _cylinder

Specify center point of base or [3P/2P/Ttr/Elliptical]: 0.000 100.000 -4.000

Specify base radius or [Diameter] <17.5000>: d

Specify diameter <35.0000>: 40

Specify height or [2Point/Axis endpoint] <-4.0000>: -6

Command:

Command:

Command: _cylinder

Specify center point of base or [3P/2P/Ttr/Elliptical]: 0.000 100.000 -10.000

Specify base radius or [Diameter] <20.0000>: d

Specify diameter <40.0000>: 30

Specify height or [2Point/Axis endpoint] <-6.0000>: -37

Command: '_zoom

Specify corner of window, enter a scale factor (nX or nXP), or

[All/Center/Dynamic/Extents/Previous/Scale/Window/Object] <real time>: _all

Regenerating model.

Command: ucs

Current ucs name: *WORLD*

Specify origin of UCS or [Face/NAmed/OBject/Previous/View/World/X/Y/Z/ZAxis]

<World>: n

Specify origin of new UCS or [ZAxis/3point/OBject/Face/View/X/Y/Z] <0,0,0>: x

Specify rotation angle about X axis <90>:

Command:

Command: _cylinder

Specify center point of base or [3P/2P/Ttr/Elliptical]: 0.000 124.000 -47.000

Specify base radius or [Diameter] <15.0000>: d

Specify diameter <30.0000>: 38

Specify height or [2Point/Axis endpoint] <-37.0000>: 45

Command:

Command:

Command: _cylinder

Specify center point o f base or [3P/2P/Ttr/Elliptical]: 0.000 -47.000 -78.000

Specify base radius or [Diameter] <19.0000>: d

Specify diameter <38.0000>: 34

Specify height or [2Point/Axis endpoint] <45.0000>: 8

Command:

Command:

Command: _cylinder

Specify center point of base or [3P/2P/Ttr/Elliptical]: 0.000 -47.000 -70.000

Specify base radius or [Diameter] <17.0000>: d

Specify diameter <34.0000>: 22

Specify height or [2Point/Axis endpoint] <8.0000>: -4

Command:




Command:

Command: _circle Specify center point for circle or [3P/2P/Ttr (tan tan

radius)]:

Specify radius of circle or [Diameter]: d

Specify diameter of circle: 25

Command:

Command:

Command: _line Specify first point:

Specify next point or [Undo]: 50

Command:

Command: _circle Specify center point for circle or [3P/2P/Ttr (tan tan

radius)]:

Specify radius of circle or [Diameter] <12.5000>: d

Specify diameter of circle <25.0000>: 18

Command:

Command:

Command: _line Specify first point:

Specify next point or [Undo]:

Specify next point or [Undo]:

Specify next point or [Close/Undo]:

Specify next point or [Close/Undo]:

Command:

Command:

Command: _boundary

Pick internal point: Selecting everything

Selecting everything visible

Analyzing the selected data

Analyzing internal islands

Pick internal point:

BOUNDARY created 1 polyline

Command:

Command:

Command: _line Specify first point:

Specify next point or [Undo]:

Command: revolve

Current wire frame density: ISOLINES=4

Select objects to revolve: 1 found

Select objects to revolve:

Specify axis start point or define axis by [Object/X/Y/Z] <Object>:

Select an object:

Specify angle of revolution or [STart angle] <360>:

Command:

Command: _.erase 1 found

Command:

Command:

Command:

Command: _move 1 found

Command:

Command: ucs

Current ucs name: *WORLD*

Specify origin of UCS or [Face/NAmed/OBject/Previous/View/World/X/Y/Z/ZAxis]

<World>: n

Specify origin of new UCS or [ZAxis/3point/OBject/Face/View/X/Y/Z] <0,0,0>: x

Specify rotation angle about X axis <90>: -90

Command: _cylinder

Specify center point of base or [3P/2P/Ttr/Elliptical]: 0.000 -86.000 -100.000

Specify base radius or [Diameter] <12.0000>: d

Specify diameter <24.0000>: 24

Specify height or [2Point/Axis endpoint] <-16.0000>: 18

Command:

Command:

Command:

Command:

Command: _chamfer

(TRIM mode) Current chamfer Dist1 = 2.0000, Dist2 = 2.0000

Select first line or [Undo/Polyline/Distance/Angle/Trim/mEthod/Multiple]:

Base surface selection

Enter surface selection option [Next/OK (current)] <OK>:

Specify base surface chamfer distance <2.0000>:

Specify other surface chamfer distance <2.0000>:

Select an edge or [Loop]: Select an edge or [Loop]:

Command:

Command:

Command: _cylinder

Specify center point of base or [3P/2P/Ttr/Elliptical]: 0.000 100.000 18.000

Specify base radius or [Diameter] <12.0000>: d

Specify diameter <24.0000>: 12

Specify height or [2Point/Axis endpoint] <16.0000>: -104

Command:

Command:

Command: _subtract Select solids and regions to subtract from ..

Select objects: 1 found

Select objects: 1 found, 2 total

Select objects: 1 found, 3 total

Select objects: 1 found, 4 total

Select objects: 1 found, 5 total

Select objects: 1 found, 6 total

Select objects: 1 found, 7 total

Select objects: 1 found, 8 total

Select objects:

Select solids and regions to subtract ..

Select objects: 1 found

Select objects: 1 found, 2 total

Select objects: 1 found, 3 total

Select objects:

Command: _vscurrent

Enter an option [2dwireframe/3dwireframe/3dHidden/Realistic/Conceptual/Other]

<2dwireframe>: _other

Enter a visual style name or [?]: Conceptual

Command: '_3DFOrbit Press ESC or ENTER to exit, or right-click to display

shortcut-menu.

Command:

Automatic save to C:DOCUME~1ADMINI~1LOCALS~1TempDrawing1_1_1_1764.sv$
