Video-88AGP-3D NVIDIA Vanta - Users Manual

manuals



+ Font mai mare | - Font mai mic



Video-88AGP-3D




NVIDIA Vanta

Users Manual

version 1.00

Contents

Introduction

Great output, reasonable performance

The power to propel you ahead

Features

Host Interface

Graphics Architecture

2D Acceleration

3D Graphics Processor

Support for Standards

Video

VIDEO SCALER PIPELINE

System Requirement

Check List

Hardware Description

Hardware Installation

Installation Procedures

Steps:

Software Installation

Microsoft Windows9x

Welcome screen from Video-88AGP-3D CD

Microsoft NT4.0

Technical Assistance

Frequently Asked Questions (FAQ)

Pinout and Sync Frequencies

Analog Color Display Pinouts (DB 15)

Conversion Table: Pin Adapters

9-to-15 Pin Conversion Table

Technical Support

Limited Warranty.

Other Limits.

Exclusive Obligation.

Other Statements.

Terms and Conditions.

Services agreement:

Entire Obligation.

Reducing Warranty Claim Rejections.

Introduction


The NVIDIA Vanta is a highly integrated 3D/2D graphics processor. Leveraging the RIVA TnT2 core technology, NVIDIA Vanta delivers break-through 3D and 2D graphics performance. In addition to its outstanding graphics capabilities, the NVIDIA Vanta provides complete support for video, software and hardware DVD playback, as well as support for the latest system technology such as AGP 4X bus and flat panel display. NVIDIA Vanta display driver are WHQL certified for windows 2000, windows NT 4.0, windows95/98. Video-88AGP-3D is full-featured graphics solution for mainstream corporate desktops.

Great output, reasonable performance

Like other TNT cards, the Video-88AGP-3D offers exceptional image quality at upto 1920x1200 pixel resolution. Even at high resolution and color depth, the windows displays are sharp and glitch-free. On 3D performance, games play beautifully with vibrant colors and no noticeable rendering errors. Video-88AGP-3D did impressively well in games performance, topping the chart in Frames-Per-Second performance.

The power to propel you ahead

Now for the manufacturer don't have to sacrifice one feature in order to gain superiority in another. Video-88AGP-3D delivers unique performance across the board, regardless of the application - 3D Games, Productivity and Lifestyle Applications, VRML, Web Browsing, Video Conferencing, Video Capture and Playback and more. Equally important, all popular PC standards are supported, including VGA, SVGA, Direct3D and AGP. Video-88AGP-3D (NVIDIA Vanta) technology has the graphics fired up to launch you ahead of the competition right from the start.

Features


Video-88AGP-3D (NVIDIA Vanta) that meets all the requirements of the mainstream PC graphics market.

Host Interface

The host interface boosts communication between the host CPU and the NVIDIA Vanta through AGP 4x pipelined transfers. The optimized interface performs variable length burst DMA bus mastering for efficient data transfers archiving over 900Mbytes/s measured throughput.

AGP 4x, 2x mode

66MHz AGP clock rate, bursting at 266 Mega-transfers per second

Supports over 900 Mbytes/s in AGP 4x modem

Fully supports the AGP Execute mode

The host interface supports burst transactions up to 266 MHz and provides over 900 Mbytes/s on AGP.

AGP accesses offer other performance enhancement since they are from non-cacheable memory (no snoop) and can be low priority to prevent processor stalls, or high priority to prevent graphics engine stalls.

Graphics Architecture

Video-88AGP-3D (NVIDIA Vanta) architecture process 2 pixels-per-clock cycle enabling single-pass multi-texturing. Video-88AGP-3D (NVIDIA Vanta)s 32-bit color pipeline, 24-bit Z-buffering, 8-bit stencil buffer and per-pixel mip-mapping precision delivers unsurpassed quality and performance allowing developers to write standards based applications with stunning visual effects and realism.

2D Acceleration

Video-88AGP-3Ds 2D rendering engine exploits the internal wide cache RAMs and 256-bit data paths to deliver industry-leading Windows acceleration performance. The 64-bit graphics engine is optimized for single cycle operation into the 64-bit SDRAM/SGRAM interface supporting over 1.0 Gbyte/s throughput. Acceleration functions are optimized for minimal software overhead on key GDI calls and demands of DirectDraw in Windows 9x including optimized Direct framebuffer (DFB) access with write-combining. Other features include:

Accelerated primitives including BLT, indexed DIB, color translation, transparent BLT, stretchBLT, points lins, lines, polylines, polygons, fills, patterns, arbitrary rectangular clipping and fast text rendering from a hardware font cache

pipeline optimized for multiple color depths including 8, 15, 16, 24, and 32 bits per pixel

DMA Pusher allows the 2D graphics pipeline to load rendering methods optimizing Vanta/host multi-tasking

Execution of all 256 Raster Operations (as defined by Microsoft Windows) at 8, 15, 16, 24, and 32-bit color depths

True color hardware cursor

Hardware color dithering

Multi buffering (Double, Triple, Quad buffering) for smooth animation

3D Graphics Processor

The NVIDIA Vanta 3D triangle setup and rendering pipeline represents a major advance graphics device integration. The NVIDIA Vanta 3D pipeline maintains the highest vertex, Z-buffer, texture filtering and rendering accuracy and yet maintains super high rendering throughput to achieve visually stunning interactive 3D:

Optimized Direct3D acceleration

Complete DirectX 6.0 support

100% hardware triangle setup

Twin texel (TNT) 32-bit graphics pipeline

2 texture mapped, Lit pixels per clock

Single pass multi-texturing support

Square and non-square texture support

Texture Blend support examples:

Multi-texture

Bump map

Texture modulation

Light maps

Reflection maps

Detail textures

Environmental maps

Procedural textures

Support for Standards

Multimedia support for MS-DOS, Windows 9x, and Windows NT4.0

Windows 95 and Windows 98 Display Driver, Direct3D, DirectVideo, ActiveX, DirectDraw and Open GL ICD for Windows 98, Windows NT

VGA and SVGA: Video-88AGP-3D (NVIDIA Vanta) has an industry standard 32-bit VGA core and BIOS support. In PCI configuration space the VGA can be enable and disable independently of the GUI.

Glue-less Accelerated Graphics Port (AGP 1.0 and AGP 2.0) interface

VESA DDC2B+, DPMS, VBE 2.0 supported

Video

Video-88AGP-3D (NVIDIA Vanta) accelerates full motion video playback under DirectDraw using hardware overlay scaling and color space conversion integrated into the Palette-DAC pipeline. This overlay pipeline features smooth up and down scaling with multitap X and Y sub-pixel interpolation, optional edged enhancement and per-pixel color keying. Interlaced video is double buffered at 60Hz with both odd and even fields displayed.

VIDEO SCALER PIPELINE

Video-88AGP-3D (NVIDIA Vanta) video scaler pipeline performs stretching of video images in any arbitrary factor in both horizontal and vertical directions. The video scaler pipeline consists of the following stages:

Vertical stretching

Filtering

Color space conversion

Horizontal stretching

Vertical stretching

Vertical stretching is performed on pixels prior to color conversion. The video scaler linearly interpolates the pixels in the vertical direction using an internal buffer which stores the previous line of pixel information.

Filtering

After vertical interpolation, the pixels are horizon-tally filtered using an edge-enhancement or a smoothing filter. The edge-enhancement filter enhances picture transition information to prevent loss of image clarity following the smoothing filtering stage. The smoothing filter is a low-pass filter that reduces the noise in the source image.

Color space conversion

The video overlay pipeline logic converts images from YUV 4:2:2 format to 24-bit RGB true-color. The default color conversion coefficients convert from YCrCb to gamma corrected RGB. Saturation controls make sure that the conversion does not exceed the output range. Four control flags in the color converter provides 16 sets of color conversion coefficients to allow adjustment of the hue and saturation. The brightness of each R G B component can also be individually adjusted, similar to the brightness controls of the monitor.

Horizontal stretching

Horizontal stretching is done in 24-bit RGB space after color conversion. Each component is linearly interpolated using a triangle 2-tap filter.

Windowing and panning

Video images are clipped to a rectangular window by a pair of registers specifying the position and width. By programming the video start address and the video pitch, the video overlay logic also supports a panning window that can zoom into a portion of the source image.

Video composition

With the color keying feature enabled, a programmable key in the graphics pixel stream allows selection of either the video or the graphics output on a pixel by pixel basis. Color keying allows any arbitrary portions of the video to overlay the graphics. With color keying disabled and video overlay turned on, the video output overlays the graphics in the video window.

Interlaced video

The video overlay can display both non-interlaced and interlaced video. Traditional video overlay hardware typically drops every other field of an interlaced video stream, resulting in a low frame rate. Some solutions have attempted to overcome the this problem by de-interlacing the fields into a single frame. This however introduces motion artifacts. Fast moving objects appearing in different positions in different fields, when de-interlaced, introduces visible artifacts which look like hair-like lines projecting out of the object.

System Requirement

Intel Pentium II or compatible system with AGP Bus Extension Slot

CD-ROM drive, Double speed or faster

Hard Drive with at least 10MB Free space



MS Windows 95/98 or Windows NT4.0 operating system

USB supplemental driver for mainboards core-logic chipset

Check List

R       Video-88AGP-3D (NVIDIA Vanta) Accelerator

R       Software & Documents CD

R       Quick Start Guide (Printed)

Hardware Description

PCB Layout

Hardware Installation

Installation Procedures

!! Warning !!

Discharge static electricity by touching the GROUND such as metal part of your case connected with good power ground before you handle the electronic circuit boards.

The manufacturer assumes no liability for any damage, caused directly or indirectly, by improper installation of any components by unauthorized service personnel. If you do not feel comfortable performing the installation, consult with a qualified computer technician.

Steps:

Turn OFF all powers to your system, including any peripherals (printer, external drives, modem, etc.).

Disconnect the power cord and the monitor cable from the back of the computer.

Unfasten the cover mounting screws on your system and remove the system cover. Refer to your system user manual for instructions to determine the location of the mounting screws.

Remove the retaining screw that holds the slot cover in place. Slide the slot cover out and put the screw aside (you will need it to secure the adapter).

To install the adapter in AGP expansion slot, carefully line up the gold-fingered edge connector on the adapter directly above the expansion slot connector on the motherboard. Then press the adapter into place, completely. Use the (remaining) screw you removed to secure the adapter retaining bracket in place.

Replace the computer cover. Secure the cover with the mounting screws you removed in Step 3.

You have now completed the installation of your new graphics adapter on your system.

< Very Important Note

Before software installation for the video adapter, you have to install USB driver for the mainboards PCI bridge functions. Otherwise, video driver installation wont go through probably.

Software Installation

Microsoft Windows95

Welcome screen from Video-88AGP-3D CD

This CD supports Windows95,and Windows98 autorun feature. Welcome menu will appear automatically on the screen after the CD is inserted to the CD-ROM drive.

Start Windows 9x with VGA or SVGA drive detected.

Insert the display Driver CD into your CD-ROM drive (e.g. X: .

Autorun file pops up Welcome screen (Master Installer) from Jaton CD.

Click on the Display Driver selection bar.

Switch to Settings tab, then click on Advance button.

Click on Change, then Have Disk.

Browse to X: V-88Win95Jaton.INF (X is the letter of your CD-ROM drive), and click OK.

The display device selected Video-88-AGP-3D, NVIDIA Vanta, then press on OK button.

Close and apply to finish AGPs display driver installation.

Restart Windows to complete installation.

Windows 98 Display Driver Installation:

The steps are as same as Windows95s installation, but the path for subdirectory V-88Win98 is instead.

Microsoft NT4.0

Select the Display icon in control panel and then SELECT the Settings page.

SELECT Display Type button in the Settings page.

SELECT Change button from the Adapter type section.

Select Have Disk button from the Change Display page.

Microsoft Windows NT 4.0 will prompt you for the correct path where the video drivers are located. Enter the path X:V-88Winnt4 where X: is the CD ROM drive where the Software & Documents CD has been inserted.

If the driver NVIDIA Vanta is listed under the Display list, SELECT the OK button to continue.

Once the driver files are copied, RESTART Microsoft Windows NT 4.0 for the changes to take effect.

SELECT the desired color palette (the number of colors), desktop area (resolution), and refresh frequency in the settings page of Display Properties and then SELECT the Test button in the same page to determine whether your selection works properly. SELECT Apply to active the selected mode.

Note: The procedure of display driver installation it required setup with service pack3 (Microsoft Windows NT4.0) first.

Technical Assistance

Q: Why is the display shifted or changed sizes when I switch display modes?

Explain and Suggestion:

Some monitors lack auto-sizing features or just do not synchronize properly to the video board output. In some cases, horizontal and vertical display adjustments may be necessary. Use the monitor control panel functions to adjust screen.

In other cases, mode type and refresh rate adjustments may be necessary. Use the utility program, which provided by video card manufacturer or production developer. To centering the display with normal type (mode 3), and to reduce (decrease) the refresh rate with the monitor's specification.

Q: What kind monitors can display 800x600 mode or higher resolution mode?

Explain and Suggestion:

To display 800x600 resolution at 60Hz refresh rate, the monitor must be capable of synchronizing a 31.5KHz horizontal scan rate (e.g., NEC 2A, 3D). At 72Hz refresh rate, the monitor must be capable of synchronizing a 48.0KHz scan rate (e.g., Sony HG 1304, NEC 4D, 5D, Seiko 1450).

To display 1024x768 interlaced mode; the monitor must be capable of synchronizing a 35.5KHz horizontal scan rate (e.g., NEC 3D, Seiko 1430 or 1440). To display 1024x768 non-interlaced mode at 60Hz, the monitor must be capable of synchronizing a 48.7KHz scan rate (e.g., Sony HG 1304, NEC 4D, 5D, Seiko 1450).

To display 1024x768 non-interlaced mode at 70Hz, the monitor must be capable of synchronizing a 56.4KHz scan rate (e.g., NEC 4D).

Q: Windows screen won't come up, it kicks back to

DOS prompt. Why?

Explain and Suggestion:

Windows 95

Inadvertently, certain configuration files (e.g., msdos.sys, and command.com) have been changed in the system. Proceed to correct that, is re-boot the system with a system (Windows 95) formatted floppy diskette.

There are many reasons to causing the system booting-up with un-appropriated steps. Base on Microsoft support wizard on their WEBsite, there are many technical articles to help users with this subject, such as troubleshooting with VXD errors, virus, Fatal exceptions, etc., more details cover on each issue are descriptive and familiar with, and exclusively further to our support.

Q: System hangs-up after installing video driver.

Explain and Suggestion:

Today, most video drivers are developed for 32-bit processing and may require a channel to Code/Decode. Conflict between device drivers and TSR (terminate-and-stay-resident) programs will inverted the display, and are particularly effectual at crashing computer. The most effective way to check for conflicts is to replace with the original video driver, or delete and re-install the current video driver to the system.

Accomplishing IRQs (Interrupt Request Query) settings or troubleshooting the conflicts on hardware source may necessary. Most AGP video cards designed for Plug-n-Play, that means video card IRQ's setup which controls by main boards (motherboard) circuitry and BIOS. Physically pulling out other devices from system, and re-starts the computer. Confirm and modify your IRQ addresses with qualified computer technician.

Q: Multiple images or unreadable screen after loading video driver.

Explain and Suggestion:

There are a variety of reasons why the display might be distorted. One common reason is a monitor mis-match. Some older multifrequency monitors are unable to switch video modes without being turned off, then turned on again.

If the problem occurring in windows, make sure that you have loaded that proper video driver, and that the driver is compatible with the monitor being used. Try re-configuring your application software to use a compatible video mode. If problem persist in windows, load the standard generic VGA driver. The generic VGA driver should function properly with virtually every video board and VGA (or SVGA) monitor available.

If that is an unsatisfactory solution, you may have to upgrade to a monitor that supports the desired video mode.

Some new monitors are also synchronizing this problem because built-in DDC (Data-Digital-Channel) feature. Sometime that DDC automatically setup the display frequency without loading video driver. Try to turn it off, or change settings of monitor type in your system.

Q: Selection of color, resolution and refresh rate combination that always backs to default after restart the system.

Explain and Suggestion:

Accordingly, there must be a bug (defected source-code) in video driver, or in the system. Debug the source-code or fix the error in video driver, that should be done by the driver developer. Likewise, upgrade the video driver from the manufacturer or from the original software developer is necessary.

Frequently Asked Questions (FAQ)

Q1 Why do we need 3D graphics capability in our PC?

Answer

3D technology is becoming increasingly important (and common) not only in games, but also in other applications such as VRML, which allows 3D scene descriptions in Web applications. 3D technology is used for image editing, modeling, and an increasing number of in home and business applications. In games, as well as other applications, 3D acceleration not only allows better visual qualities and more realistic scenery attributes than software alone, but it also allows a higher frame rate, which translates into a more interactive experience for the end user.

Q2 What does Rendering Engine mean?

Answer

Rendering Engine generically applies to the part of the graphics engine that draws 3D primitives, usually triangles. In most implementations, the rendering engine is responsible for interpolation of edges and 'filling in' the triangle.

Q3 What does the set-up engine do in a graphics controller?

Answer

A set-up engine allows drivers to pass triangles in the form of raw vertex information; whereas, most common designs force triangles to be pre-processed for the rendering engine in terms of delta values for edges, color, and texture.

Q4 Why does a 3D graphics chip need to have both a rendering engine and a setup engine?

Answer

Any 3D application, a game, VRML, or modeling package, can benefit from 3D rendering. This is especially true of applications that uses texturing extensively, because texturing and texture filtering are very intensive operations at the pixel level in terms of CPU operations and demands for memory bandwidth. Without a set-up engine in a graphics controller, the CPU has to calculate the delta values for edges, color, and textures; the drivers need to handle ten (10) times more extensive data. This results in slower 3D pipeline operations between the CPU and the graphics controller.

Q5 If we use powerful CPUs, such as a Pentium 200, can a standard 2D graphics card achieve 3D performance?

Answer

Yes and no. Software rendering can take advantage of 'tricks' learned by force of necessity through years of trial and error. With such stratagems, the speed of software rendering for simple scenes can approach that of low-level hardware 3D rendering. On the other hand, as scenes become more complex (or frame sizes become larger), there are conflicts between using the CPU for high-level game logic, geometry, lighting, and rendering, all of which increase their demands. No current CPU or system can perform advanced quality-enhancements (bilinear filtering and alpha blending) in real time. Even general case texture mapping with RGB lighting is too much for the current CPU generation.

Q6 What does 'software 3D' mean?

Answer

Software 3D is generally used to mean using non-specific (2D) hardware in conjunction with the CPU to render for 3D applications. Some of these techniques allow usable 3D applications when high-powered and/or MMX-equipped CPU's are employed along with special-case software optimization techniques. As stated above, SW 3D can achieve credible results with today's (software optimized) applications, but the rising popularity of good 3D hardware at the consumer price level is inexorably compelling the public to expect hardware level scene enhancements and frame rates.

Q7 What is SGRAM?

Answer

Synchronous Graphics Random Access Memory (SGRAM) is a new and improved type of memory, custom-designed for graphics use.

Q8 What is the advantage of as compared to ordinary DRAM?

Answer

is now capable of running at much higher speeds than Fast Page Mode or EDO DRAM. Also, is able to execute a small number of frequently executed operations, such as buffer clears, specific to graphics applications, independently of the controller.

Pinout and Sync Frequencies

Analog Color Display Pinouts (DB 15)

Pin



Function

Red Video1

Green Video1

Blue Video1

Not Used

Ground

Red Return (ground)

Green Return (ground)

Blue Return (ground)

Vcc (+5v DDC Power)

Sync Return (ground)

Monitor ID (not used)

SDA (DDC support)

Horizontal Sync

Vertical Sync

SCL (DDC support)



Note: Analog monochrome type monitors use green video for all video input and ignore red and blue video.

Conversion Table: Pin Adapters

If you will be using a 9-to-15-pin adapter cable to link your 9-pin monitor connector to the 15 pin accelerator card connector, check Table carefully before you install the cable. The 9-to-15 pin adapter cables are available from a variety of sources, but they need to match the specifications in Table to work properly with your new card.

The adapter cable requires a D-shaped 9 pin female connector and a D-shaped 15 pin male connector.

9-to-15 Pin Conversion Table

9 pin Signals

Pin No.

15 pin Signals

Pin no.

Red

Red

Green

Green

Blue

Blue

Horz Sync

Horz Sync

Vert Sync

Vert Sync

Red Ground

Return Red

Green Ground

Return Green

Blue Ground

Return Blue

Sync Ground

Digital Ground

Ground

Analog Video Signals

Black Level = 0 V

Full Intensity (White) Level = +0.7 V

Technical Support

In the event you have a technical problem with this product, please read the README files in the software CD_ROM. Updated drivers are available through Jaton Web site. Have following information handy when you contact technical support:

t       Name of the product.

t       Software Driver and Version.

t       System Information, such as CPU speed, BIOS version, Monitor Specification, etc.

t       Description of the problems including any error messages.

Telephone:

(408) 934-9369 9-5 PST Mon. - Fri.

FAX:

email:

vgasupport@jaton.com

URL

www.jaton.com

NOTICE

The information in this document is subject to change in order to improve reliability, design, or function without prior notice and does not represent a commitment on the part of the company. In no event will the company be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or the inability to use the product or documentation, even if advised of the possibility of such damages. No part of this manual may be reproduced or transmitted in any form or by any means without the prior written permission of the company.

AUG 1999, Rev. A

FCC Shielded Cable Warning:

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. Operation is subject to the following conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation,

SHIELD INTERFERENCE CABLE (S) MUST BE USED ACCORDING TO FCC 15.27.

CAUTION:

Changes or modifications not expressly approved by the Manufacturer could void your authority to operate this equipment in accordance with FCC rules and regulations.

Software License Agreement:

The Company grants the customer a non-exclusive, non-transferable license to use the software in this package for internal use on a single computer system. No other license of any kind is granted to any part of the product or any of the intellectual property therein.

Trademark and Copyright:

All Trademarks and Registered Trademarks belong to respective owners.

a1999 Jaton Corporation. All rights reserved.

Limited Warranty.

Manufacturer warrants that the products sold hereunder are free from defects in material and workmanship for a period of two (2) years from manufacturing date. This limited warranty applies only to the original purchaser of Jaton Product and is not transferable. This limited warranty does not apply if failure to the Product Registration, or over thirty (30) days from purchase (original invoice date). This Limited Warranty does not cover any incompatibilities due to the users computer, hardware, software or any related system configuration in which the Jaton Products interfaces. Proof of purchase will be require before any consideration by Manufacturer occurs.

Other Limits.

The forgoing is in lieu of all other warranties, expressed or implied. Including but not limited to the implied warranties of merchantability and fitness for a particular purpose. Manufacturer does not warrant against damages or defects arising out of improper or abnormal use of handling of the products; against defects or damages arising from improper installation (where installation is by persons other than Manufacturer), against defects in products or components not manufactured or installed by Manufacturer, or against damages result from non-manufacturer made products or components. This warranty does not apply if the Product has been damaged by accident, abuse, nor misuse. This warranty also does not apply to products upon which repairs have been effected or attempted by persons other than pursuant to written authorization by Manufacturer.

Exclusive Obligation.

This warranty is exclusive. The sole and exclusive obligation of Manufacturer shall repair or replace the defective products in the manner and for the period provided above. Manufacturer shall not have any other obligation with respect to the Products or any part thereof, whether based on contract, tort, strict liability or otherwise. Under no circumstances, whether based on this Limited Warranty or otherwise, Manufacturer shall not be liable for incidental, special, or consequential damage.

Other Statements.

Manufacturers employees or representatives ORAL OR OTHER WRITTEN STATEMENTS DO NOT CONSTITUE WARRANTIES, shall not be relied upon by Buyer, and are not a part of the contract for sale or this Limited Warranty.

Terms and Conditions.

Direct Jaton Customer: This warranty applies only for a period of two (2) years from purchase date of Jaton original invoice.

Reseller/ Vendor: This warranty applies only for a period of two (2) years from manufacturing date.

Registered User: This warranty applies only for a period of two (2) years from purchase date and register within 30 days of purchase date from legal reseller.

Others: If the products do not conform to this Limited Warranty (as herein above described), Manufacturer should charge services such as repair, replacement whether based on its costs. Shipping and installation of the replacement Products or replacement parts shall be at Users expanse.

Services agreement:

All applicants shall completed service request form from Manufacturer.

All returned checks will be charged a $20.00 fee by Manufacturer.

All repair and replacement services allow 4-6 weeks from the date of receiving by Manufacturer.

All products without warranties require service processing fee $20 (payment in advance), which is not refundable.

Entire Obligation.

This Limited Warranty states the entire obligation of Manufacturer with respect to the Products. If any part of this Limited Warranty is determined to be void or illegal, the remainder shall remain in force and effect. Some states do not allow limitation of implied warranties, or exclusive or limitation on product incidental or consequential damages, so above limitation may not apply to you. This warranty gives you specific legal rights. You may have other rights which may vary from state to state.

This warranty applies only to this product, and is governed by the law of the State of California.

Reducing Warranty Claim Rejections.

To reduce the potential of incurring damages not covered by Manufacturers warranties, we strongly recommend the following:

read your manuals before installing peripherals and/or before making changes to the machines configuration;

ask your dealer if there are any known problems with the system requirements or installation procedures for any add-on products that your are purchasing;

buy industry standard products where compatibility issue are more likely to surface;

If you are unsure about installation for a new product, contact your dealers service department.

We believe it is important for you to know and understand what your warranty coverage provides and what it does not.

We also want you to be aware that most hardware warranties only relate to the function of the hardware. In most cases, no assurances are given by the manufacturer that the hardware item will work in conjunction with any other hardware item. If a computer product is not working because it is not compatible with another product, or because it has not been properly installed and set-up, the manufacturer does not pay for the service time. To help avoid these inconveniences, contact a professional consultant that one can help you determine the possibility of incompatibility issue before you purchase add-on or accessories.





Politica de confidentialitate | Termeni si conditii de utilizare



DISTRIBUIE DOCUMENTUL

Comentarii


Vizualizari: 1286
Importanta: rank

Comenteaza documentul:

Te rugam sa te autentifici sau sa iti faci cont pentru a putea comenta

Creaza cont nou

Termeni si conditii de utilizare | Contact
© SCRIGROUP 2024 . All rights reserved
